产品特色

 产品规格

 ‧ Output Ratings at 40°C
 ‧ Output voltage: 0 to 60 V
 ‧ Output current: 0 to 2.5 A
 ‧ Maximum power: 150 W
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.03% + 27 mV
 ‧ Current 0.03% + 1.2 mA
 ‧
 ‧ Ripple & Noise (20 Hz to 20 MHz)
 ‧ Constant Voltage rms: 9 mV
 ‧ Peak-to-Peak: 15 mV
 ‧ Constant Current rms: 1 mA
 ‧
 ‧ Readback Accuracy (via GPIB or keyboard display at
 ‧ Voltage 0.02%+ 16 mV
 ‧ Current 0.02%+ 1 mA

 应用范围
