 ‧ Output Ratings
 ‧ Voltage: 35 V
 ‧ Current (derated 1% per °C above 40°C): 1.5 A / 3 A
 ‧ Power: 52.5 W / 105 W
 ‧
 ‧ Programming Accuracy (at 23°C ±5°C
 ‧ Voltage: 0.1% + 35 mV
 ‧ Current: 0.15% + 20 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ CV peak-to-peak: 15 mV
 ‧ CV rms: 5 mV
 ‧ (PARD) CC rms: 2 mA
 ‧
 ‧ Load Effect (Regulation) (for any output load chan
 ‧ Voltage: 11 mV
 ‧ Current: 2 mA
