產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 0 to 500 V
 ‧ Current: 0 to 5 A
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage: 0.25% + 400 mV
 ‧ Current: 0.3% + 63 mA
 ‧
 ‧ Ripple & Noise 20 Hz to 20 MHz
 ‧ Voltage rms: 50 mV
 ‧ Voltage Peak-to-Peak: 160 mV
 ‧ Current rms: 50 mA
 ‧
 ‧ Readback Accuracy at 25°C ±5°C
 ‧ Voltage: 0.5%, +200 mV
 ‧ Current: 0.5%, +50 mA

 應用範圍
