產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 0-15 V
 ‧ Current Derated linearly 1%/°C from 40°C to 55°C: 0-440 A
 ‧
 ‧ Programming accuracy at (@ 25 ±5°C)
 ‧ Voltage: 0.04% + 15 mV
 ‧ Current: 0. l % + 230 mA
 ‧
 ‧ Ripple & Noise (20 Hz to 20 MHz)
 ‧ Constant Voltage: rms: 2.5 mV
 ‧ Constant Voltage: peak-to-peak: 15 mV
 ‧ Constant Current With load inductance >5 µH rms: 200 mA
 ‧
 ‧ Readback Accuracy (from front panel or over GPIB w
 ‧ Voltage: 0.05% + 22.5 mV
 ‧ ±Current: 0.1% + 300 mA

 應用範圍
