產品特色

 產品規格

 ‧ Output Ratings at 40°C
 ‧ Output voltage: 0 to 120 V
 ‧ Output current: 0 to 1.25 A
 ‧ Maximum power: 150 W
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.03% + 54 mV
 ‧ Current 0.03% + 0.6 mA
 ‧
 ‧ Ripple & Noise (20 Hz to 20 MHz)
 ‧ Constant Voltage rms: 18 mV
 ‧ Peak-to-Peak: 25 mV
 ‧ Constant Current rms: 1 mA
 ‧
 ‧ Readback Accuracy (via GPIB or keyboard display at
 ‧ Voltage 0.02%+ 32 mV
 ‧ Current 0.02%+ 0.6 mA

 應用範圍
