產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 8 V
 ‧ Current (derated 1% per °C above 40°C): 6.25 A / 12.5 A
 ‧ Power: 50 W / 100 W
 ‧
 ‧ Programming Accuracy (at 23°C ±5°C
 ‧ Voltage: 0.1% + 19 mV
 ‧ Current: 0.15% + 20 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ CV peak-to-peak: 12 mV
 ‧ CV rms: 2 mV
 ‧ (PARD) CC rms: 4 mA
 ‧
 ‧ Load Effect (Regulation) (for any output load chan
 ‧ Voltage: 6 mV
 ‧ Current: 2 mA
 ‧

 應用範圍
