產品特色

 產品規格

 ‧ Output Ratings (@ 0°C to 40°C)
 ‧ Voltage: 0 to 35 V / 2.2 A
 ‧ Current: 0 to 60 V / 1.3 A
 ‧
 ‧ Programming Accuracy (@ 25°C ±5°C),
 ‧ Voltage: <0.05% + 10 mV (<0.1% + 25 mV for output 2 of E3646/47/48/49A)
 ‧ Current: <0.2% + 10 mA
 ‧
 ‧ Ripple & Noise 20 Hz to 20 MHz
 ‧ Normal Mode Voltage: <5 mVpp / 0.5 mVrms for 8 V / 20 V models, <8 mVpp / 1 mVrms for 35 V / 60 V models
 ‧ Normal Mode Current: <4 mArms
 ‧ Common Mode Current: <1.5 uArms
 ‧
 ‧ Readback Accuracy (@ 25°C ±5°C), &p
 ‧ Voltage: <0.05% + 5 mV (<0.1% + 25 mV for output 2 of E3646/47/48/49A)
 ‧ Current: <0.15% + 5 mA (<0.15% + 10 mA for output 2 of E3646/47/48/49A)

 應用範圍
