產品特色

 產品規格

 ‧ Output Ratings
 ‧ Output Voltage: 0 to 60 V
 ‧ Output Current: (40° C) 0 to 3.5 A
 ‧ Maximum Current (50° C/55° C): 3.2 A/3 A
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.06% + 26 mV
 ‧ Current 0.14% + 4.1 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ Voltage rms: 500 µV
 ‧ Peak-to-Peak: 5 mV
 ‧ Current rms: 1.5 mA
 ‧
 ‧ Load and Line Regulation
 ‧ Load Voltage: 4 mV
 ‧ Load Current: 0.25 mA
 ‧ Line Voltage: 1 mV
 ‧ Line Current: 0.25 mA

 應用範圍
