產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 50 V
 ‧ Current (derated 1% per °C above 40°C): 5 A / 10 A
 ‧ Power: 50 W / 100 W
 ‧
 ‧ Programming Accuracy (at 23°C ±5°C
 ‧ Voltage high range: 0.06% + 19 mV
 ‧ Voltage low range (≤ 5.5 V): N/A
 ‧ Current high range: 0.1% + 20 mA
 ‧ Current low range (≤ 100 mA, @ 0 - 7 V): N/A
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ CV peak-to-peak: 4.5 mV
 ‧ CV rms: 350 µV
 ‧ (PARD) CC rms: 2 mA
 ‧
 ‧ Load Effect (Regulation) (for any output load chan
 ‧ Voltage: 2 mV
 ‧ Current (@ 0 - 7 V): 2 mA
 ‧ (@ 0 - 50 V): 2 mA

 應用範圍
