產品特色

 產品規格

 ‧ Output Ratings
 ‧ Output Voltage: 0 to 35 V
 ‧ Output Current: (40° C) 0 to 6 A
 ‧ Maximum Current (50° C/55° C): 5.4 A/5.1 A
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.06% + 15 mV
 ‧ Current 0.14% + 6.7 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ Voltage rms: 400 µV
 ‧ Peak-to-Peak: 4 mV
 ‧ Current rms: 3 mA
 ‧
 ‧ Load and Line Regulation
 ‧ Load Voltage: 3 mV
 ‧ Load Current: 0.25 mA
 ‧ Line Voltage: 1 mV
 ‧ Line Current: 0.25 mA

 應用範圍
