產品特色

 產品規格

 ‧ Output Ratings
 ‧ Output Voltage: 0 to 120 V
 ‧ Output Current: (40° C) 0 to 1.5 A
 ‧ Maximum Current (50° C/55° C): 1.4 A/1.3 A
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.06% + 51 mV
 ‧ Current 0.14% + 1.7 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ Voltage rms: 700 µV
 ‧ Peak-to-Peak: 7 mV
 ‧ Current rms: 1 mA
 ‧
 ‧ Load and Line Regulation
 ‧ Load Voltage: 5 mV
 ‧ Load Current: 0.25 mA
 ‧ Line Voltage: 2 mV
 ‧ Line Current: 0.25 mA

 應用範圍
