產品特色
產品規格
‧ Output Ratings ‧ Voltage: 60 V ‧ Current (derated 1% per °C above 40°C): 0.8 A / 1.6 A ‧ Power: 50 W / 100 W ‧ ‧ Programming Accuracy (at 23°C ±5°C ‧ Voltage: 0.1% + 60 mV ‧ Current: 0.15% + 20 mA ‧ ‧ Ripple & Noise from 20 Hz to 20 MHz ‧ CV peak-to-peak: 25 mV ‧ CV rms: 9 mV ‧ (PARD) CC rms: 2 mA ‧ ‧ Load Effect (Regulation) (for any output load chan ‧ Voltage: 13 mV / 16 mV ‧ Current: 2 mA
應用範圍
