產品特色

 產品規格

 ‧ Output Ratings at 40°C
 ‧ Output voltage: 0 to 20 V
 ‧ Output current: 0 to 7.5 A
 ‧ Maximum power: 150 W
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.03% + 8 mV
 ‧ Current 0.03% + 3 mA
 ‧
 ‧ Ripple & Noise (20 Hz to 20 MHz)
 ‧ Constant Voltage rms: 3 mV
 ‧ Peak-to-Peak: 7 mV
 ‧ Constant Current rms: 4 mA
 ‧
 ‧ Readback Accuracy (via GPIB or keyboard display at
 ‧ Voltage 0.02%+ 5 mV
 ‧ Current 0.02%+ 3 mA

 應用範圍
