產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 20 V
 ‧ Current (derated 1% per °C above 40°C): 15 A
 ‧ Power: 300 W
 ‧
 ‧ Programming Accuracy (at 23°C ±5°C
 ‧ Voltage: 0.1% + 20 mV
 ‧ Current: 0.15% + 60 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ CV peak-to-peak: 20 mV
 ‧ CV rms: 3 mV
 ‧ (PARD) CC rms: 6 mA
 ‧
 ‧ Load Effect (Regulation) (for any output load chan
 ‧ Voltage: 13 mV
 ‧ Current: 6 mA

 應用範圍
