產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 0 to 5 V
 ‧ Current (40°C then derate linearly 1%/°C from 40°C to 55°C): 0 to 875 A
 ‧
 ‧ Programming accuracy at (@ 25 ±5°C)
 ‧ Voltage 0.04% + 5 mV
 ‧ Current 0.1% + 450 mA
 ‧
 ‧ Ripple and Noise Constant Voltage Mode from 20 Hz
 ‧ rms: 1.5 mV
 ‧ Peak to peak: 10 mV
 ‧
 ‧ Readback Accuracy at 25°C ±5°C
 ‧ Voltage 0.05% + 7.5 mV
 ‧ Current 0.1% + 600 mA

 應用範圍
