產品特色
產品規格
‧ Output Ratings ‧ Voltage: 35 V ‧ Current (derated 1% per °C above 40°C): 8.5 A ‧ Power: 300 W ‧ ‧ Programming Accuracy (at 23°C ±5°C ‧ Voltage: 0.1% + 35 mV ‧ Current: 0.15% + 60 mA ‧ ‧ Ripple & Noise from 20 Hz to 20 MHz ‧ CV peak-to-peak: 22 mV ‧ CV rms: 5 mV ‧ (PARD) CC rms: 6 mA ‧ ‧ Load Effect (Regulation) (for any output load chan ‧ Voltage: 16 mV ‧ Current: 6 mA
應用範圍
