產品特色

 產品規格

 ‧ Output Ratings
 ‧ Voltage: 12.5 V
 ‧ Current: 120 A
 ‧ Power: 1500 W
 ‧
 ‧ Programming Accuracy
 ‧ Voltage 0.05%+ 6.25 mV
 ‧ Current 0.1%+ 120 mA
 ‧
 ‧ Ripple & Noise
 ‧ CV p-p: 60 mV
 ‧ CV rms: 8 mV
 ‧ CC rms: 240 mA
 ‧
 ‧ Load Regulation
 ‧ Load Effect (change from 10% to 90%) Voltage: 3.25 mV
 ‧ Load Effect (change from 10% to 90%) Current: 29 mA
 ‧ Load Transient Recovery Time: ≤1.5 ms

 應用範圍
