產品特色

 產品規格

 ‧ Output Ratings
 ‧ Output voltage: 0 to 8 V
 ‧ Output current (40° C): 0 to 50 A
 ‧ Maximum current (50° C/55° C): 45 A/42.5 A
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.06% + 5 mV
 ‧ Current 0.15% + 60 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ Voltage rms: 300 µV
 ‧ Peak-to-Peak: 3 mV
 ‧ Current rms: 25 mA
 ‧
 ‧ Load and Line Regulation
 ‧ Load Voltage: 1 mV
 ‧ Load Current: 2 mA
 ‧ Line Voltage: 0.5 mV
 ‧ Line Current: 2 mA

 應用範圍
