產品特色

 產品規格

 ‧ Output Ratings
 ‧ Output voltage: 0 to 35 V
 ‧ Output current (40° C): 0 to 15 A
 ‧ Maximum current (50° C/55° C): 13.5 A/12.8 A
 ‧
 ‧ Programming Accuracy at 25°C ±5°C
 ‧ Voltage 0.06% + 15 mV
 ‧ Current 0.15% + 13 mA
 ‧
 ‧ Ripple & Noise from 20 Hz to 20 MHz
 ‧ Voltage rms: 400 µV
 ‧ Peak-to-Peak: 4 mV
 ‧ Current rms: 5 mA
 ‧
 ‧ Load and Line Regulation
 ‧ Load Voltage: 3 mV
 ‧ Load Current: 0.5 mA
 ‧ Line Voltage: 1 mV
 ‧ Line Current: 0.75 mA

 應用範圍
